Product Details
- Size: 22
- Place of Origin: luoyang
- Brand Name: lutong
- Model Number: LTC208
- Weight: 8000.000 kg
| MODEL | LTC212 LTC214 | LTC210 LTC208 | |
| Travel speed | km/h | 0-12 | 0-11.1 |
| Turning radius | mm | 7000 | 6000 |
| Grade ability | % | 40 | 40 |
| Steering angle | ° | ±35 | ±35 |
| Drum diameter | mm | 1350 | 1150 |
| Drum width | mm | 2100 | 1730 |
| Drum rim thickness | mm | 20 | 16 |
| Transverse swing angle of the vibrating wheel | ° | ±8 | ±8 |
| Type of water spray | mm | pressure | pressure |
| Wheel base | mm | 3717 | 3217 |
| Overall length | mm | 5060 | 4558 |
| Overall width | mm | 2250 | 1840 |
| Overall hieght | mm | 3300 | 2674 |
| Ground clearance | mm | 324 | 324 |
| Diesel model | cummins 6BT5.9 | cummins 4BT3.9 | |
| Diesel power | kW | 110 | 75 |
| Diesel speed | r/min | 2300 | 2400 |
- Size: 22
- Place of Origin: luoyang
- Brand Name: lutong
- Model Number: LTC208
- Weight: 8000.000 kg
