Product Details
- Size: 35
- Place of Origin: henan
- Brand Name: lutong
- Model Number: LT220B
- Weight: 12000.000 kg
| LT212 | LT214 | LT216B | LT218B | LT220B | ||
| Operating mass | Kg | 12000 | 14000 | 16000 | 18000 | 20000 |
| Static linear load | N/cm | 276 | 342 | 378 | 415 | 450 |
| Vibration amplitude | Hz | 30 | 30 | 30 | 30 | 30 |
| Vibration fraquency | mm | 1.8 | 1.8/0.9 | 2.0/1.0 | 1.0 | 2.0 |
| Centrifugal force | kN | 270/140 | 200/150 | 320/180 | 340/200 | 360/220 |
| Travel speed | Hz | |||||
| 1st gear | 1.8 | 2.0 | 2.0 | 2.0 | 2.0 | |
| 2nd gear | 3.7 | 4.0 | 4.0 | 4.0 | 4.0 | |
| 3rd gear | 9.7 | 10.5 | 10.5 | 10.5 | 10.5 | |
| Grade ability | % | 35 | 35 | 35 | 35 | 35 |
| Turning angle | 35 | 35 | 35 | 35 | 35 | |
| Ground clearance | mm | 360 | 432 | 432 | 432 | 432 |
| Bectrical voltage | v | 24 | 24 | 24 | 24 | 24 |
| Turning radius | mm | 7000 | 7000 | 7500 | 7500 | 7500 |
| Vertical oascill ation | 8 | 8 | 8 | 8 | 8 | |
| Type size | 17.5-25 | 23.1-26 | 23.1-26 | 23.1-26 | 23.1-26 | |
| Overall length | mm | 5640 | 5820 | 5820 | 5820 | 5820 |
| Overall width | mm | 2258 | 2278 | 2278 | 2280 | 2280 |
| Overall hieght | mm | 2970 | 3000 | 3000 | 3000 | 3000 |
| Vibration round width | mm | 2100 | 2100 | 2100 | 2100 | 2100 |
| Drum diameter | mm | 1400 | 1600 | 1600 | 1600 | 1600 |
| Drum rim thickness | mm | 24 | 24 | 32 | 40 | 46 |
| Wheelbase | mm | 3080 | 3160 | 3160 | 3160 | 3160 |
| Diesel model | YC6108G | YC6108G | YC6108ZG | YC6108ZG | D6114ZG6B | |
| Diesel power | kW | 85 | 88 | 110 | 110 | 132 |
| Diesel speed | r/min | 2000 | 2000 | 2000 | 2000 | 2000 |
| Fuel tank capacity | L | 180 | 180 | 180 | 180 | 180 |
| Hydraulic tank capacity | L | 150 | 150 | 150 | 150 | 150 |
